Capacity
Swing over ("Z Axis Cover) diameter : 380 mm
Swing over cross slide diameter : 120 mm
Max turning diameter : 100 mm
Max bar capacity : 25 mm

Spindle
Chuck size : ø 130 mm
Spindle speed : 50 - 4000 rpm
Spindle nose DIN 55026 : A2 - 4
Spindle through bore : 38 mm

Travel
X axis travel : 200 mm
Z axis travel : 265 mm

Feed rate
Rapid traverse X axis : 20 mts./min
Rapid traverse Z axis : 25 mts./min
Feed Rate : 6000 mm

Tooling
Tooling arrangement : Linear Tooling
Tool size : 20 x 20 mm
Boring Bar size : ø 25 mm

Machine Size
Machine height : 1540 mm
Floor Space : 1550 x 1550 mm
Machine weight : 1300 kg

CNC Controller
Siemens - 808 D PPU 161/828D/
FANUC - OiTF/Mitsubishi-E-80

Motor Power
Spindle drive motor - continuous rating : V0-4kW-GDW (Mitsubishi/Siemens)
V1-3.7kW (Siemens/Fanuc/Mitsubishi)
V2-5.5kW (Siemens/Fanuc/Mitsubishi)

Accessories
Hydraulic chuck and Closed
Cylinder
One set of soft jaws
Hydraulic Power Pack
Coolant supply equipment
Centralized lubrication
Equipment
Chip Trolley
Work light
Foot Switch
Linear tool holder blocks
2 Turning holder blocks
2 Boring holder blocks
Set of Manuals
Machine mounting pads
