Worktable size 600*1200 mm
Max. loading weight 800 kg
X/Y/Z travel 1100/600/600 mm
Spindle nose to table surface 120-720 mm
Spindle center to column surface 650 mm
Spindle speed range 10000 rpm
Spindle taper BT40
Rapid feed speed X/Y/Z 36/36/32 m/min
Spindle dia. 150 mm
Tools magazine capacity/type 24/arm
Main motor power 11 kw
Positioning accuracy ±0.005 mm
Repeatability ±0.003 mm
Overall size 5200*3440*2800 mm
Net weight 6800 kg

Accessories
SIEMENS 828D
THK linear guide way
NSK bearings
Center lubrication Japan HERG
Electrical type spindle unit
Chip tray
Taiwan ball screw bar, linear guide way
Heat exchanger in e-cabinet
Taiwan tools magazine
Working light
