Capacity
Swing over bed - diameter : 475 mm
Swing over cross slide cover - diameter : 225 mm
Admid Between centers Min/Max : 30 / 550 mm
Maximum turning dia. & Length (Without chuck) : 170 x 320 mm
Maximum bar capacity - diameter : 42 mm

Spindle
Chuck size - diameter : 165 mm
Spindle through bore - diameter : 58 mm
Spindle nose DIN 55026 type A2-5 LB
Spindle speed : 50 - 4000 rpm
Spindle C axis (Live Tool) Continuous Feed

Travel
X axis travel : 155 mm
Z axis travel : 590 mm

Feed Rate
Rapid traverse X axis : 20 mts./min
Rapid traverse Z axis : 25 mts./min
Feed Rate : 6000 mm/min

Turret
No. of tool positions : 12-2 pitch diameter
Tool Shank size : 20 x 20
Boring Bar size - diameter : 32

Tailstock
Quill diameter : 60 mm
Quill stroke : 100 mm
Quill taper : MT 5

Machine Size
Floor Space (LxWxH) : 2200 x 1700 x 2050 mm
Machine Weight (Approx.) : 2000 kg

CNC Controller
Siemens/Fanuc/Mitsubishi type 828D /Oi TF/E-80

Motor Power
Spindle motor rated power (Continous rating) : V2-5.5KW Siemens/Fanuc/Mit

Accessories
Hydraulic 165X3 Jaw chuck and Closed cylinder
One set of soft jaws
Hydraulic Tailstock
Hydraulic Power pack
Coolant supply equipment
Centralized lubrication equipment
Chip trolley
Work light
Foot Switch for Chuck
12 Station-2 Pitch disc bidirectional
"PRAGATI DTT 80" Live tool Turret
