Capacity
Center Height : 125 mm
Swing Diameter Over Bed : 250 mm
Distance Between Center : 500 mm
Spindle Nose Bayonet : Din 55027, Size 4
Swing over cross slide : 140 mm
Spindle Bore : 38 mm
Collet Capacity : 26 mm

Tailstock
Tailstock Spindle Travel : 80 mm
Tailstock taper in spindle : MT3
Hand Wheel Diameter Graduation : 0.05 mm

Carriage
Dial graduation of apron hand wheel : 0.2 mm
Cross slide travel : 90 mm
Dial graduation of cross slide : 0.05 mm
Top slide travel : 100 mm
Dial graduation of top slide : 0.05 mm
Angular swivel graduation : ± 45°
Max. tool section : 16 x 16 mm

Feed & Threads No/Range
Longitudinal Feed : 24/0.03-0.7
Cross Feed : 24/0.15-0.35
Metric Threads : 32/0.15-12 mm
US & Whitworth Threads : 39/90-2 TPI
Module Threads : 37/0.1 to 2.5
Diametral Threads : 27/8-200

Motor Power : 1.3/1.6 kW

No. of Speeds : 18

Speed Range : 50-3000

Accessories
MT5-MT3 center sleeve
MT3-male center
Quick change tool
Electric coolant system
Set of change gears
Drive plate
Service tools
