Capacity
Centre Height : 165 mm
Swing over bed : 330 mm
Swing over cross slide : 190 mm
Swing over carriage guide ways : 300 mm
Distance between centers in accordance with DIN 806 : 670 mm
Width of Bed : 220 mm
Height of Bed : 220 mm
Spindle height form floor : 1150 mm

Spindle
Spindle nose bayonet DIN 55027 : Size 5
Spindle bore dia : 43 mm
Maximum Collet bore size : 26 mm
I.D Taper bore similar to DIN 228 : ME 50
Chuck size : 165 dia mm
Max diameter of face plate : 280 mm

Tool Slide
Cross slide travel : 165 mm
Top slide travel : 115 mm
Swivel range of top slide : +75°/-65°
Cross-section of cutting tool :  20 x 20 mm
Lead screw pitch : 6 mm

Tail Stock
Quill stroke : 85 mm
Quill diameter : 45 mm
Taper bore in accordance with DIN 228 : MT 3

Drive
Spindle Drive : Gear Box Drive
Speed range : 60 - 3000 U/min
Motor power : 2.2/3 kW

Feeds & Thread Range
Longitudinal Feeds : 0.025 - 0.09 mm/U
Cross feeds : 0.009 - 0.032 mm/U
Metric threads : 0.2 - 7 mm
With worth threads : 80 - 5 TPI
Module threads : 0.12 - 3.15
Diameter pitch threads : 200 - 12

Machine Size
Dimensions (LxWxH) : 1450 x 855 x 1650 mm
Weight : 1100 kg
