Max. swing dia. over bed mm 500
Max. cutting length mm 500
Max. cutting dia. mm 360
Max. swing dia. over carriage 340 mm
Spindle nose A2-6
Spindle dia. 65 mm
Spindle speed 50-4500 rpm
Main motor 11 kw
X/Z rapid speed 30/30 m/min
Feedrate 0.001 - 6 mm/rev
X/Z travel 200/550 mm
Tailstock unit travel 450 mm
Tailstock sleeve travel 100 mm
Tailstock taper 5#
Machining accuracy IT6
X/Z position accuracy 0.008 mm
X/Z repeatability position accuracy 0.004 mm
Machining roughness 1.25μm
Machine size 2300*1700*1930 mm

Accessories
GSK999TA controller
Imported ball screw, linear guide way, bearings
Taiwan 8” hydraulic chuck
Taiwan 8 position hydraulic turret
Chip tray
Automatic center lubrication
