Horizontal table size (LxW) : 320x750 mm
T-slots (pc*size*center distance) : 5/14/63 mm
Vertical table size (LxW) : 225x890 mm
T-slots (pc*size*center distance) : 3/14/63 mm
Maximum table load : 160 kg
X/Y/Z axes travel : 405/305/400 mm
Spindle taper (H. & V.) : ISO 40
Spindle speeds (H. & V., variable) : 40-2000
Stroke of vertical spindle quill : 60 mm
Feed rate (X/Y/Z axes) : 10-1000 mm/min
Rapid traverse (X/Y/Z axes) : 1200 mm/min
Main motor power : 3.7 kW
Feed motor torque (X/Y/Z axes) : 7.7/7.7/10
Machine weight : 1450 kg
Machine dimensions (LxWxH) : 1500x1700x1800 mm

Accessories
Digital Read Out (DRO)
Horizontal milling arbor and support
Coolant system and chip tray
Reducing sleeves (MT 1, 2, 3)
Automatic lubrication system
Draw bar
Work light
4 Milling arbors (diameter 16, 22, 27, 32 mm)
Collect chuck with collets (2, 3, 4, 5, 6, 8, 10, 12 mm)
Chip collector tray
Oscillation elements
Outer arbor support for horizontal milling
Operating instructions
Operating tools
